Portable High Frequency Induction Heater 40KW For Bolts And
Bearings
Features of portable induction heating machine:
1) EASY TO MOVE: for complex and inaccessible workpieces or
workshop locations, hand-held type is small-sized, simple operation
and move easily, it can easily do induction brazing.
2) QUIET AND COMFORTABLE: Induction heating is quiet and
comfortable, it won't cause the temperature surrounding environment
to rise.
3) STRONG CONTROLLABILITY: The controllable induction heating and
accurate heat transfer reduce the risk of overheating, thus
avoiding the damage to the workpiece and reducing the loss to the
maximum extent.
4) ACCURATE OPERATION: High frequency, stable heating output, no
vibration during working heating, accurate welding position, the
minimum diameter 0.1mm of metal can be welded and the sensor can be
customized according to the different shape of the workpiece.
5) REDUCE COST: Efficient and accurate heating ensures the
qualification of primary welding, making the waste, rework and
energy consumption to the minimum extent.
6) EASY TO OPERATE: When brazing, it is not necessary to carry or
store bulk workpiece near brazing equipment, it is an ideal choice
for online brazing.
Applications of portable induction heating machine:
It's applied to refrigeration and HVAC industry, automobile
industry, household electrical appliance industry, medical
equipment and so on.
Applicable process: valve parts of air conditioning refrigeration,
refrigerator freezer pipeline, accessories of solar, parts of
compressor, washing machine (pipe connections, tube and shell
connection, pipe and valve connection), auto parts of the
connection between the evaporator and the compressor, such as
soldering process of the short circuit loop of the motor.
Technical parameters of high frequency induction heating machine:
Control Mode | All Digital Circuit Control |
Working Mode | Manual Mode/Automatic Mode |
Number of Heating Current Setting | 5-stage |
The number of stored workpiece parameters | 10/Mode |
Content of Working status | Time, Current |
Alarm Interface | Overcurrent, overpressure, under water, undervoltage, phase loss,
overheat. ect. |
Model | PHC-S-40 |
Output power | 4-40KVA |
Output frequency range | 10~60KHz |
Length of Main Extendion Cable | 2-5m |
Input Voltage | 380V±10% |
Input Frequency | 50/60Hz |
Input power factor | 0.95 |
Min Circuit Breaker | 3P-63A |
Max Inlet Water Temp | 35℃ |
Water Pressure(Max/min) | 4/6bar |
Working Environment Temp | +5℃~+50℃ |
Overall Dimensions(L*W*H) | 600*400*620 |
FAQ:
Q: How to choose suiteble induction heating machine?
A: You can tell us your application,need
forging,hardening,welding,melting or other,
pass me workpiece material & size,Temperature requirement and
heating time requirement.
Then we will recommend fit machine for you reference.
Q: How about the induction heating machine payment
term&delivery time&Shipping term?
A: Our company payment term accept T/T,Western Union,L/C and so
on.Small machine delivery
time is 3~7 workdays.Big machine delivery time 15~25
workdays.Shipping term accept EXW,FOB,
CIF and so on.
Q:How about the induction heating machine warranty?
A:Our goods support one year warranty not by personal
purpose,support technical service all life.
During the warranty,if machine have problem need change spare
parts,we can replace for you charge free.
