380V 50Hz Copper Tube Welding Machine High Frequency Induction
Heating Brazing Machine
Features of induction brazing machine:
(1) Using the well-known international company Mosfet/IGBT power
devices and unique inverter technology, 100% duty cycle design,
24-hour operation at maximum power, high reliability assurance.
(2) Self-controlled adjustable heating time, heating power, holding
time, holding power and cooling time; greatly improve the quality
and repeatability of heating heating products, to simplify the
operation of technical workers.
(3) Light weight, small size, simple installation a few minutes to
complete.
(4) Simple, few minutes to learn.
(5) Special Security, the output voltage is below 36V, remove the
high voltage electric shock.
(6) The heating efficiency up to 95%, energy consumption is only
20% -30% of the old-fashioned tube, almost no electricity in
standby mode, and 24 hours of continuous work.
(7) The sensor can be freely removable quick replacement,
ultra-fast heating significantly reduced the oxidation of the
workpiece deformation.
(8) Substituted oxygen, acetylene, coal and other dangerous items
heated latest environmentally friendly products, no open flame to
produce more safe and secure.
(9) The device has over-current, over voltage, over temperature,
water shortages, lack of equal perfect automatic protection
function, and is equipped with self-diagnostic alarm system.
(10) The apparatus includes a constant current and constant power
control function, greatly optimize the process of heating the metal
to achieve efficient, rapid heating, the superiority of the product
can be fully realized.
Technical parameters induction brazing machine:
Item Model | GP-60 |
| Rated Voltage(V) | 380V/50Hz |
| Input Power(kVA) | 5~60 |
| Input Oscillation Frequency(kHz) | 30~60 |
| Load Duration | 100% |
| Cooling Water Pressure(Mpa) | 0.15~0.3 |
| Output Water Flow(L/Min) | 25~35 |
Induction Heating Brazing Application:
1. welding/brazing for carbide saw blade tooth;
2. welding/brazing and annealing for spectacle frames and its spare
parts;
3. welding/brazing/heating for jewelry & watches;
4. Electronics Industry: tin/silver/copper brazing/soldering for
very small evenΦ0.1mm below wire and pieces of various electronic
components;
5. Electromechanical industry: silver brazing for metal joints,
quenching and tempering for micro motor & shaft;
6. Wire Industry: wire strip annealing;
7. Welding tools, cutter, hardening for shoe mouth & blade;
8. Toy Industry: winding thin metal sheet tempering.
Delivery process:
